C Series BIM models RCA/IFC
Download the zip file of C Series BIM models and extract them to a folder on your computer.
Flat copper tape, printed warning tape and direct burial cable BIM models RCA/IFC
Download the zip file of cable and tape BIM models and extract them to a folder on your computer.
Ampetronic are always listening to our customers which is why we’ve seen the growing requirement for modern projects to be designed in a fully digital BIM environment.
As part of our expansion of the C-Series range we can now provide BIM models in both REVIT and IFC format for the entire series of amplifiers. The models are all BIM Level 2 COBie compliant.
These include all variants whether you want them wall mounted, in a 19” rack, networked or Dante enabled, it’s all there in each model.
In addition there are also models available for our cables and tapes to ensure the correct data is provided at every level.
This allows for better planning and maintainability of your assistive listening systems, ultimately ensuring a better provision for the end users.
Download the models now and get started integrating Ampetronic hearing loops into your next project.
Perimeter loop drivers
C5-1 – 5ARMS output, single channel, 20VRMS
C7-1 – 7ARMS output, single channel, 20VRMS
C10-1 – 10ARMS output, single channel, 33.9VRMS
MultiLoop drivers
C5-2 – 5ARMS output, two channels, 20VRMS
C7-2 – 7ARMS output, two channels, 20VRMS
C10-2 – 10ARMS output, two channels, 33.9VRMS
C14-2 – 14ARMS output, two channels, 48.1VRMS
